Have fun locking/unlocking your parameters!įor more information on the software solutions, training and consulting Ideate provides, please visit the Ideate, Inc. i.e.: “Created by Ron copyright 2012” The value within the quotes will be grayed out within the parameter value column. If you want to have a grayed out value such as the creator/manufacturer name place the parameter value inside of quotes. On a similar note, if you are creating families and want to gray out parameter values from being editable, in the Formula column, enter two quotes “” to gray out the parameter value. This will make the parameter’s value available for editing. To make the parameter editable, remove the characters in the Formula for the parameter you would like to make editable.
Note here in Figure 2 that the Description does not have a formula, but the has the Value of the description in quotes. Basically parameters that have formulas become non-editable parameters and are hence grayed out.
With Identity Data expanded, you may see grayed out parameters. This is often collapsed making it difficult for users to locate and edit. Note that in the Identity Data section press the down arrow in the heading. Problem was the description was grayed out, and the value could not be edited.Īfter editing the family we went to the Family Types dialog box and expanded the Identity Data Section. This was a family created by a manufacturer and the user wanted to change the default description. Working as the Ideate Support Tech the other day, I ran into a question where a user wanted to change a value of a parameter within a family.
